Synology DiskStation DS1618+ - Add a RAM Module on DiskStation

10
Chapter 2: Hardware Setup
Add a RAM Module on DiskStation
The optional Synology DDR4 RAM module is designed for DiskStation memory expansion. Follow the steps
below to install, check, or remove a RAM module on your DiskStation.
To install the RAM module:
1
Press and hold the power button until you hear a beep sound to shut down your DiskStation. Disconnect all
cables from your DiskStation to prevent any possible damage.
2
The RAM modules are located at the bottom of DS1618+.
3
Remove the 2 screws that secure the bottom lid. Lift o󰀨 the lid and place it to the side. You will see one 4GB
module pre-installed.
Important:
When you remove the lid, you expose sensitive internal components. Avoid touching anything other than
the memory assembly when you remove or add memory.
