Setting Up Hardware Components PCIe IP Prototyping Kit Installation Guide
Figure 1-4 PCIe Endpoint IP Prototyping Kit Components with Xilinx PHY on HAPS-80
HAPS-80
SD
Card
PCIE-8_PDL_MGB
PCIe x8 Extender Cable
RISER1_MGB
