Status LEDs PCIe IP Prototyping Kit Installation Guide
A.4 ARC HSDK Development Kit Board LEDs
The ARC HSDK includes the following LEDs:
■
4 user LEDs
■
4 status/system LEDs.
Table A-5 summarizes the status/system LEDs. The user LEDs can be controlled through the I/O expander
using the on-board I2C bus
Table A-5 ARC HSDK Status and System LEDs
LED Color Description
RST red Reset LED, this LED turns red if the ARC HSDK is in Reset.
TUN green Tunnel BIST, indicates that the AXI Tunnel self-test is OK after connecting
ARC HSDK on a HAPS system through the HapsTrak 3 connectors.
PM blue The ARC HSDK is in Peripheral MODE. This mode is currently not available.
PWR green Indicates that the power supplies for the ARC HSDK are OK.
