Status LEDs PCIe IP Prototyping Kit Installation Guide
A.1 HAPS-80 Supervision LEDs
Figure A-1 illustrates the HAPS-80 supervision LEDs location, see Table A-1 for the LEDs description.
Figure A-1 HAPS-80 LEDs Location
Table A-1 describes the HAPS-80 supervision LEDs colors and the status they indicate. The following list
represents the color code for the supervision LEDs.
Green Amber Red Unlit
Table A-1 HAPS-80 Supervision LED State and Description
LED Color Description
SDCARD SD Card is available
Flash configuration in progress
No SD Card or no access
RESET off
Reset is released for all FPGAs
Reset is active
