PCIe IP Prototyping Kit Installation Guide Status LEDs
READY off
Supervisor is ready
Supervisor power OK
+12 V
ALERT FPGA configuration in progress
No alert
FPGA temperature over limit
PWR
(Power)
FPGA power off
FPGA power OK
FPGA power failure
SVDONE Supervisor is configured
UDONE FPGA is configured
MDONE Supervisor (CLPD) is configured
Table A-1 HAPS-80 Supervision LED State and Description (Continued)
LED Color Description
