Synrad Firestar Series User Manual

maintenance/
troubleshooting
67
SYNRAD OEM v30 Operator’s Manual Version 2
Troubleshooting
Operational owchart
The owchart below illustrates the OEM v30’s start-up sequence.
Figure 5-1 Operational owchart
Ye s
No
PWR
(Power)
indicator Green?
RDY
(Ready)
indicator
Yellow?
Check DC power cable
connections, fuse, and
DC voltage levels
Check Laser Enable
input voltage
Apply tickle pulses for
5–10 seconds and then
send PWM Command
signals to laser
Apply 30 VDC
power to laser
Laser Start Sequence
No
Refer to Operator’s
Manual and troubleshoot/
correct fault condition
Apply +5 VDC Laser
Enable input
Verify laser temp is within
limits. If not, cool laser,
and then cycle DC power
Flashing
Ye s
LASE indicator
illuminates Red to
indicate laser output
Flashing
