SYNRAD OEM v30 Operator’s Manual Version 2
Troubleshooting
Table 5-10 Laser Enable input not connected
LED Indicator LED Status Output Signal RJ45 Output Status
LASE (if tickle applied) O n/a – –
LASE (if PWM applied) O n/a – –
RDY O Laser OK Low
Temperature OK High
PWR Green Voltage OK High
Table 5-11 Over Temperature fault
LED Indicator LED Status Output Signal RJ45 Output Status
LASE (if tickle applied) O n/a – –
LASE (if PWM applied) O n/a – –
RDY Flashing
1
Laser OK Low
Temperature OK
1
Low
PWR Green Voltage OK High
1 See the Laser fault indications section for details.
Table 5-12 DC Voltage fault
LED Indicator LED Status Output Signal RJ45 Output Status
LASE (if tickle applied) O n/a – –
LASE (if PWM applied) O n/a – –
RDY O Laser OK Low
Temperature OK High
PWR Blinking
1
Voltage OK
1
Low
1 See the Laser fault indications section for details.
