机床产品/Machine Tool Products – 60CA/60CB Simple-Type Wood Cutting Machine Operation Manual
Fenu and System Introduction– 19
•
1.
2.
3.
•
•
•
•
i.
ii.
•
•
•
•
•
•
•
•
•
•
a.
b.
c.
d.
Setting Ways There are 3 ways provided to set the double sort function.
Prefix name rule, the string fix at front of ncfiles' name (ex:
F_00001.nc)
Suffix name rule, the string fix at end of ncfiles' name (ex:
00001_F.nc)
Normal, the station will show 1,2,1,2,repeatly, but no sort the file
sequence.
the fix string can be defined on the screen.
Limitation MUST CHECK! the file name rule comes with some limitation
Only fix the string at the Start or End of NCfile !
If eliminate the fix string of the NCfiles for the same panel,
the 2 name need to be the same.
Suffix Example：0001_F.nc, 0001_Z.nc eliminate
"_F" and "_Z", get the same result 0001.nc
Prefix Example：5_0001.nc, 8_0001.nceliminate
"5_" and "8_", get the same result0001.nc
At least 1 information need to be set in Back side string or
Front side string.
Each panel "MUST" have front side program, the back side
program is not necessary
Result After Setting the double sort setting parameters, the sequence
will be arranged automatically while output workinglist.
The work station will show as 1,2,1,2...repeatly
If the last panel comes with back side and front side program, the
station value will show as 1,2,1,2,1,1 or 1,2,1,2,2
Do the back side first and do the front side
Example
Test Example Sort Result
1 Prefix name rule，
Front Side: Z_
Back Side: F_
F_0001.nc , Z_0001.nc
Z_0002.nc
Z_0003.nc
F_0004.nc , Z_0004.nc
Sort Work Station
F_0001 1
Z_0002 2
Z_0001 1
Z_0003 2
F_0004 1
F_0004 1
To Next Page
