System Sensor 6424 - Rear View Receiver; Rear View Transmitter

Figure 14. Rear view receiver:
ACCESS DOOR
CONNECTOR
16 CONDUCTOR
CABLE
RESET SWITCH
30
55
SENSITIVITY
SELECT SWITCH
N
A
ALIGNMENT
MODE SWITCH
A78-2032-01
Figure 15. Rear view transmitter:
ACCESS DOOR
CONNECTOR
6 CONDUCTOR
CABLE
A
N
ALIGNMENT
MODE SWITCH
SW1
L
S
RANGE
SELECT SWITCH
SW2
A78-2031-01
D400-18-00 8 I56-494-10R
