12
|
Description
Table 6 Dimensions AJ8, AJR
Size
H [mm] B [mm] E [mm] F [mm] L [mm]
AJ8 315 (B), (F)
365 375 325 678 1535
AJ8 355 (B), (F)
395 400 355 678 1695
AJ8 400 (B), (F)
445 500 460 727 1875
AJR 315 (B), (F)
365 223 265 433 1535
AJR 355 (B), (F)
465 243 305 473 1695
AJR 400 (B), (F)
505 266 350 516 1875
5.4 Description AXCBF
Directly powered axial fan with motor outside the air flow. The fan can be run in permanent operation up to a conveying
media temperature of 200°C. Maximum ambient temperature 55°C. Housing flanges on both sides with bores accord-
ing to eurovent 1/2 standard. B3 conventional motors with add-on terminal box.
| 014
