Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
→External
setpoint
External
setpoint
Notactive
Minsetpoint:
12.0°C
Maxsetpoint:
30.0°C
Setifaexternalsetpointis
used,forexamplearoom
controller.
Notactive/Active.
Setminallowedsetpointofthe
externalsetpoint.
Setmaxallowedsetpointofthe
externalsetpoint.
→Step
controllers
Stepcontrol
heating
Notinuse.
Stepcontrol
cooling
Binarysteps
Startstep1:
10%
Stopstep1:
5%
Startstep2:
50%
Stopstep2:
45%
Startstep3:
95%
Stopstep3:
90%
Setthelevelofthecooling
outputthatstartsstep1ofthe
cooling.
Setthelevelofthecooling
outputthatstopstep1ofthe
cooling.
Setthelevelofthecooling
outputthatstartsstep2ofthe
cooling.
Setthelevelofthecooling
outputthatstopstep2ofthe
cooling.
Setthelevelofthecooling
outputthatstartsstep3ofthe
cooling.
Setthelevelofthecooling
outputthatstopstep3ofthe
cooling.
→Accessrights
→LogonLogon
Enterpassword
xxxx
Actuallevel:
None
Logontoservicelevelby
enteringa4-digitcode.After
reachingthedesiredlevelgo
backwith“LEFT”arrow(press
2times)onthecontrolpanel.
Standardcodefromfactory
toenterservicelevelis2222.
Backtooperatorlevel:1111
→LogoffLogoff
No
Actual
level:None
Logofffromsystemlevelby
changing"No"to"Yes"withthe
"OK"and"UP/DOWN"buttons
Automaticlogoffafter6minutes
ofinactivity.
→Change
password
Changepassword
for
level:None
Newpassword
xxxx
Setanewpasswordforthe
levelofyourchoice.
Canonlybedoneoncelogged
ontotheservicelevel.
TopvexSR09,11,TR09-15OperationandMaintenanceInstructions
207880
22
SystemairAB
