2.2InternalcomponentsTopvexTR09-15
Fig.2Internalcomponentswithairconnectionsymbols(Drawnasalefthandunit)
PositionDescription
Symbol
A
Connectionsupplyair
B
Connectionexhaustair
CConnectionoutdoorair
D
Connectionextractair
1
Fansupplyair
2Fanextractair
3
Filtersupplyair
4Filterextractair
5
Heatexchanger
6Rotormotor
7
Controlunitheatexchanger
8
Extradrivingbelt
9
PressureguardFilters
10
Pressuretransmitterfans
1
11
Tempsensorextractair
12
Tempsensorsupplyair
13
ElectricalConnectionbox
14
Electricalre-heaterbattery
2
15
Tempsensorexhaustair
16
Tempsensoroutdoorair
1.OnlyvalidforunitswithConstantAirVolumecontrol(CAV)
2.Onlyvalidforunitswithelectricalre-heaterbattery
TopvexSR09,11,TR09-15OperationandMaintenanceInstructions
207880
3
SystemairAB
