3InterfaceDescription
3.1Operatingthecontrolpanel
TheSCPcontrolpanelisdeliveredwitha10mcablethatisconnectedtothepanelandwithafastcoupling
contact,connectedtotheT opvexunit.ThecontactisconnectedtotheCorrigocontrollerintheelectrical
connectionbox(pos.1,gure4).Thecablecanbeunscrewedinthebackofthecontrolpanel(gure5).
3.1.1Operatingthecontrolpanel
Fig.5Thecontrolpanel
PositionExplanation
1
Alarmbutton:Givesaccesstothealarmlist.
2
AlarmLED:Indicatesalarmbyashingredlight.
3
WriteLED:Indicatesbyashingyellowlightthatparameterscanbesetorchanged.
4
OKbutton:Pressthisbuttontobeabletochangeorsetparameterswheneverpossible.Also
usedtomovebetweenchangeableparametersinonedialoguewindowframe.
5
Cancelbutton:Usedtoabortachangeandreturntotheinitialsetting.
6
Right/Left&Up/Downbuttons:Usedtomoveup,down,left&rightinthemenutree.Up/Down
buttonsarealsousedtoincreaseordecreasevalueswhensettingorchangingparameters.
7
Mountingholes.
8
Connectionblock.
9
Connectiontoyellowcable.
10
Connectiontoorangecable.
11
Connectiontoredcable.
12
Connectiontobrowncable.
13
Connectiontoblackcable.
3.1.1.1Navigatingthemenus
Thestartdisplay(thedisplaynormallyshown)isattherootofthemenutree.PressingDOWNwillmove
youthroughthemenuoptions.UPwillmoveyoubackthroughtheoptions.T oenterahighermenulevel,
useUPorDOWNtoplacethecursoratthemenuyouwishtoaccessandpressRIGHT .Ifyouhave
sufcientlogonprivilegesthedisplaywillchangetothemenuyouhavechosen.
TopvexSR09,11,TR09-15OperationandMaintenanceInstructions
207880
7
SystemairAB
