T.E.L.L. EAG80 - 4.2 Menu Interfaces (Schnt); 4.2.1 Use of serial interfaces SE SC

Total no. of pages: 30
PAGE 16
Anleitung EAG80_26_00_2017_03_28_GB
Version 28.04.2017
4.2 Menu Interfaces (Schnt)
Schnt


SE SC
Use of interface
⇑ ⇓
GA TI
Transmission speed RS232
⇑ ⇓
GAINP
Function impulse large-size display
⇑ ⇓
PCCOm
Activate EAG Explorer for PC
⇑ ⇓
4.2.1 Use of serial interfaces SE SC
Function of 1st serial interface (or of 2nd interface, if available)
4.2.1.1 CON 1
Function of 1st serial interface
AuS Interface 1 deactivated
GAZ t Output format for T.E.L.L. large-size displays with
messages Start/Stop
druck Output format for T.E.L.L. printer, data logger or Telog Software
(only for protocol printing function!)
GAJun Output format for T.E.L.L. large-size display (only for Jun 1, Jun 2, Jun 3, Jun 4)
GAZ Output format for T.E.L.L. large-size display, only weight values
4.2.1.2 CON 2
Function of 2nd serial interface (optional)
AuS Interface 1 deactivated
GAZ t Output format for T.E.L.L. large-size displays with
messages Start/Stop
druck Output format for T.E.L.L. printer, data logger or Telog Software
(only for protocol printing function!)
GAJun Output format for T.E.L.L. large-size display (only for Jun 1, Jun 2, Jun 3, Jun 4)
GAZ Output format for T.E.L.L. large-size display, only weight values
4.2.1.3 bAud
Input of baud rate of serial interfaces (1 and 2)
4.2.1.4 PArIt
Input of parity of serial interfaces (1 and 2)
4.2.1.5 bIt L
Setting bit length of serial interfaces (1 and 2)
