T.E.L.L. EAG80 - 7.3 Connection board; 7.3.1 Connection of weighing elements

Total no. of pages: 30
PAGE 25
Anleitung EAG80_26_00_2017_03_28_GB
Version 28.04.2017
7.3 Connection board
1 2 3 4 5 6
1 = Connection to main board
2 = Connection weighing elements
3 = Connection input 1 and 2
4 = Fuse (1A fast)
5 = Relay
6 = Output
