Please inspect the device for damage occurred during transportation. In case of damage, the retailer has to be
informed immediately, at the latest within 8 days after the date of purchase.
2. Range of use
Booster sets from T.I.P. are self-priming electrical pumps with a mechanical or electronic pump control system for
automated operation. These high-quality products with their convincing performance data were developed for the
various purposes involved with irrigation, domestic water supply and pressure boosting, as well as for discharging
water at a constant pressure. The devices are suitable for pumping clean, clear water. The typical areas of use of
booster sets include: Automatic domestic water supply with grey water from wells and cisterns, automated
irrigation of gardens and garden beds and sprinkling. The device is not suited for use in swimming pools and for
installation into the public drinking water supply system.
This product is intended for private use in the home area and not for commercial or industrial purposes or for
continuous circulating
The pump is not suited to discharge saltwater, faeces, inflammable, etching, explosive or
other hazardous liquids. Please observe the max. and min. temperatures of the liquids to be
discharged stated in the technical data.
3. Technical Data
Model
HWW 6000 INOX NIM TLS
Mains voltage / frequency
230 V ~ 50 Hz
Nominal performance
1,300 Watt
Protection type
IP X4
Suction port
30.93 mm
(1 “)
, female
Pressure port
30.93 mm (1 “), female
Max. flow rate (Q
max
)
1)
6,000 l/h
Max. pressure
3)
5.5 bar
Max. delivery height (H
max
)
1) 3)
55 m
Max. suction height
8 m
Volume of the pressure tank
22 l
Max. size of the solids being pumped
2 mm
Max. permissible operating pressure
6 bar
Min. ambient temperature
5 °C
Max. ambient temperature
40 °C
Min. fluid temperature 2 °C
Max. fluid temperature (T
max
)
35 °C
Max. cut-in frequency in one hour
40, evenly distributed
Length of connection cable
1.5 m
Cable type
H07RN-F
Weight (net)
19,8 kg
Guaranteed sound power level (L
WA
)
2)
78,0 dB
Measured sound power level (L
WA
)
2)
73,3 dB
Sound pressure level (L
pA
)
2)
65,3 dB
Dimensions (L x D x H)
56 x 31 x 61 cm
Item no.
31320
1)
2)
The values were determined with free, unreduced in- an outlet.
Noise emission values obtained according to the EN 12639 regulation. Measurement method according to
EN ISO 3744.
3)
Due to the factory pre-set switch off pressure of the pressure switch, pressure is limited to approx. 3,8 bar
(38 m delivery head). The theoretically achievable pressure of the pump unit of the domestic water supply
can reach the value specified under “Max pressure”. Consult a qualified specialist, to adapt the pressure
circuit to your requirements if necessary, see also the chapter “Adjusting the pressure switch”.
4. Scope of delivery
The scope of the delivery of this product includes:
One booster set with a connection cord, one operating manual.
