T.I.P. Maxima 180 PX User Manual

2
2. Range of use
Submersible dirty water pumps from T.I.P. are highly efficient electrical pumps for discharging clear or dirty water
containing solids up to the maximum size specified in the technical details. These high-quality products with their
convincing performance data were developed for the multiple purposes involved with draining and pumping
liquids from one place to another.
Typical applications for waste water submersible pumps are: Emptying ponds, tanks, storage tanks, and waste
water pits, as well as emergency drainage in the event of flood or high water.
Submersible dirty water pumps from T.I.P. are suitable for stationary or temporary installations.
This product is intended for private use in the home area and not for commercial or industrial purposes or for
continuous circulating.
The pump is not suitable for use in table-top fountains, aquariums or similar ranges of use.
When using the unit in a pond, please take the required action to ensure that no inhabitants of the pond will be
sucked in.
The pump is not suited to discharge saltwater, faces, inflammable, etching, explosive or other
hazardous liquids. Please observe the max. temperature of the liquids to be discharged stated
in the technical data.
Inside the pump, lubricants are used which may contaminate the liquids being discharged in
case of any improper operation or damage of the device. The lubricants used are biologically
degradable and non-hazardous to health.
3. Technical Data
Model
Maxima 180 PX
Maxima 250 PX
Mains voltage / frequency
230 V~ / 50 Hz
230 V~ / 50 Hz
Nominal performance
500 Watt
600 Watt
Protection type
IPX8
IPX8
Pressure port
41.91 mm (1¼“), male
41.91 mm (1¼“), male
Max. flow rate (Q
max
)
1)
10.500 l/h
14.500 l/h
Max. pressure
0.7 bar
0.8 bar
Max. delivery height (H
max
)
1)
7 m
8 m
Max. submersion depth 
7 m
7 m
Max. size of the solids being pumped
25 mm
25 mm
Max. fluid temperature (T
max
)
35 °C
35 °C
Max. cut-in frequency in one hour
30, evenly distributed
30, evenly distributed
Length of connection cable
10 m
10 m
Cable type
H05RN-F
H05RN-F
Weight (net)
4.9 kg
5.4 kg
Min. self-priming level (A)
2)
103 mm
103 mm
Min. suction level (B)
2)
37 mm
37 mm
Cut-in level (C)
2)
350 mm
390 mm
Cut-out level (D)
2)
80 mm
130 mm
Dimensions (L x D x H)
20 x 16 x 34 cm
20 x 16 x 34 cm
Item no.
30121
30264
1)
2)
The values were determined with free, unreduced outlet.
The values between brackets refer to the illustrations given at the end of these operating instructions.
4. Scope of delivery
The scope of the delivery of this product includes:
One pump with connection cable, one connection port, one operating manual.
Please verify that the scope of delivery is complete. Depending on the purpose of the application, additional
accessories may be necessary (please refer to the chapters titled "Installation" and “How to order spare parts“).
If possible, keep the packing until the warranty period has expired. Please dispose of the packing materials in an
environmental-friendly manner.
