TW20_NS20_EW20 Series Weighing Indicator Operation Manual REV:01
- 9 -
NS20
No
Interface
Description
1
RS-232
For connecting computer / printer /alarm light/ Remote display
2
RJ45
Support 10M/100M Ethernet
3
USB2.0
For USB disk/ scanner /data transfer,don’t use for charging other device
4
Load cell connector
For connecting load cell
1
2
3
4
