TW20_NS20_EW20 Series Weighing Indicator Operation Manual REV:01
- 4 -
2.2 Over View
TW20
1 Keyboard
2 Preset keys
3 Indicator Holder
4 4.3” LCD display
5 AC adapter jack
6 RS232 port
7 RJ45 LAN port
8 Load cell connector
1
2
4
5
6
7
8
