28
Parameter List
Function F_ Function Description
Unit Range
Factory
setting
Page Note
0 Factory Adjustment 0 24
1 Accel. time 0.1Sec 0.1 ~ 999 S 5.0 24 *1 *3Accel. Time
Decel. Time
2 Decel. time 0.1Sec 0.1 ~ 999 S 5.0 24 *1 *3
Operation mode 3
0: Forward / Stop, Reverse / Stop
1:Run/Stop, Forward / Reverse
1 0 ~ 1 0 25
Motor rotation
direction
4
0: Forward
1: Reverse
1 0 ~ 1 0 25
*1
V/F Pattern 5 V/F pattern setting 1 1 ~ 6 1/4 26 *2
6 Frequency upper limit 0.1Hz
1.0 ~ 120Hz
(1~200)*4
50/60Hz 27
*2 *3
Frequency
upper/lower limit
7 Frequency lower limit 0.1Hz
0.0 ~ 120Hz
(1~200)*4
0.0Hz 27
*3
SPI frequency 8 SP1 frequency 0.1Hz
1.0 ~ 120Hz
(1~200)*4
10Hz 27
*3
JOG frequency 9 JOG frequency 0.1Hz
1.0 ~ 10.0Hz
(1~200)*4
6Hz 27
Start / Stop Control 10
0: Keypad
1: Terminal (TM2)
1 0 ~ 1 0 27
Frequency Control 11
0: Keypad
1: Terminal (0~10v / 0~20mA)
2: Terminal (4~20mA)
1 0 ~ 2 0 28
Carrier frequency
control
12
Carrier Frequency Setting
1
1 ~ 5
(1~10)*4
5 28
Torque compensation 13 Torque compensation gain 0.1% 0.0 ~ 10.0% 0.0% 28 *1
Stop method 14
0:controlled deceleration stop
1:free run to stop
1 0 ~ 1 0 29
15
DC braking time
0.1S 0.0 ~ 25.5S 0.5S 29
16
DC braking injection frequency
0.1Hz 1 ~ 10Hz 1.5Hz 29
DC braking setting
17
DC braking level
0.1% 0.0 ~ 20.0% 8.0% 29
Electronic thermal
Overload protection
18
Protection base on motor rated
current
1%
50 ~ 100%
(0~200)*4
100% 30
19
Multifunction input terminal 1
(SP1) function
2 31
Multifunction input
connection point
20
Multifunction input terminal 2
(RESET) function
1: Jog
2: Sp1
3: Emergency stop
4: External Base Block
5: Reset
6: SP2*4
5 31
Multi-function output 21
Multifunction output terminal 1: Operating
2: Frequency reached
3: Fault
3 32
