Air Chiller System (ACS) and Chiller Panel Getting Started Guide for the DMA 850 Page 56
Replacement Parts
Table 8: DMA 850 Chiller and Chiller Panel Replacement Parts – Rev. A
Table 7: DMA 850 Chiller and Chiller Panel Replacement Parts – Rev. B
613.06190 Air Regulator Type R07
404146.001 ACS Dryer Panel Standoff
203928.001 Locknut M4 with flange
578056.001 Black Nylon Tubing 8 mm OD x 6 mm ID
203929.901 Chiller Panel Filter Replacement Pack (filter elements for water sepera-
tor, mist filter, and micro mist filter)
203920.001 Dryer Membrane Replacement (does NOT need to be replaced on a 12
month schedule)
985730.901 Clamp Screen Kit DMA ACS
545056.901 Combined ACS Panel Upgrade Kit
405400.901
404040.90
Combined DHR/DMA Air Chiller Panel
DHR Chiller Panel
613.06190 Air Regulator Type R07
200750.001 Cinching strap 8 ft. long
578056.001 Black Nylon Tubing 8 mm OD x 6 mm ID
986301.901 Chiller Panel Filter Replacement Pack (BX filter, DX filter, Element
filter)
985730.901 Clamp Screen Kit DMA ACS
545056.901 Combined ACS Panel Upgrade Kit
405400.901
986400.901
Combined DHR/DMA Air Chiller Panel
DMA Air Chiller Panel
