Air Chiller System (ACS) and Chiller Panel Getting Started Guide for the DMA 850 Page 53
6 Turn-off source air and disconnect the 8 mm Gas In tubing from the source. NOTE: The line may be
pressurized.
7 Adjust the Anti-Tilt Bar Feet so they do not touch the floor. See Figure 8
and Figure 9.
8 Carefully move the ACS to its final location.
9 Promptly readjust the Anti-Tilt Bar Feet to touch the floor after relocation.
Removing the ACS Chiller Panel – Rev B
1 Turn off the source air and disconnect the 8 mm Gas In tubing from the source. Note: The line may be
pressurized.
2 Disconnect the 8 mm Chiller Inlet Tubing from the ACS. See Figure 16
and Figure 17.
3 Remove the (4) lock nuts and lift the Chiller panel off of the ACS unit. Note that the Panel mounting
magnets will temporarily hold the Panel in place when the locknuts are removed. See Figure 12
.
NOTE: If you are connecting the ACS to a DHR instrument using the Combined DHR/DMA Air Chiller
Panel, follow the instructions in the Air Chiller System (ACS) and Chiller Panel Getting Started Guide for
the DHR.
Removing the ACS Chiller Panel – Rev A
1 Turn off the source air and disconnect the 8 mm Gas In tubing from the source. NOTE: The line may
be pressurized.
2 Disconnect the 8 mm Chiller Inlet Tubing from the ACS. See Figure 24
, Figure 25, and Figure 26.
3 Remove the Cinching Strap. See Figure 20
.
4 Remove the standoffs as shown in Figure 18
and Figure 19
NOTE: If you are connecting the ACS to a DHR instrument using the Combined DHR/DMA Air Chiller
Panel, follow the instructions in the Air Chiller System (ACS) and Chiller Panel Getting Started Guide for
the DHR. The Q800 panel cannot be used on the DHR.
WARNING: The Chiller Panel is too heavy for one person to install safely.
AVERTISSEMENT: Le panneau de refroidissement est trop lourd pour une personne à installer
en toute sécurité.
