Air Chiller System (ACS) and Chiller Panel Getting Started Guide for the DMA 850 Page 31

8 Connect the 8 mm Chiller Inlet tubing from the Air Chiller Panel to the Inlet on the back of the ACS

unit. See Figure 24

and Figure 25.

Figure 24 DMA Air Chiller Panel, P/N 986400.901 Rev. A.

Temperature gauge

Inlet pressure regulator and gauge

Gas IN

Outlet pressure regulator

8 mm Chiller Inlet tubing

Filters and drains

Quarter-turn valve

Flow indicator ball

Dryer
