Air Chiller System (ACS) and Chiller Panel Getting Started Guide for the DMA 850 Page 15
Accessory Specifications
The tables below detail the ACS Accessory technical specifications.
*Specific refrigerant components are indicated on the serial number tag attached to each instrument.
Table 1A: ACS Accessory Characteristics with DMA 850 & Q800 Air Chiller Panel (Rev. B)
/ Combined Air Chiller Panel (Rev. B)
Specifications ACS-2 ACS-3
Dimensions of Air Chiller
(H x W x D):
Without Chiller Panel
With Chiller Panel
88.5 cm (35 in) x 37 cm (14.5 in) x
56 cm (22 in)
88.5 cm (35 in) x 52 cm (20.5 in) x
56 cm (22 in)
112 cm (44 in) x 37 cm (14.5 in) x 56
cm (22 in)
112 cm (44 in) x 52 cm (20.5 in) x 56
cm (22 in)
Weight of Air Chiller
Without Chiller Panel
With Chiller Panel
96 kg (211 lbs)
104 kg (229 lbs)
121 kg (267 lbs)
130 kg (285 lbs)
Dimensions of Chiller Panel Height: 63.5 cm (25 in)
Width: 55 cm (21.5in)
Depth: 18 cm (7 in)
Height: 63.5 cm (25 in)
Width: 55 cm (21.5 in)
Depth: 18 cm (7 in)
Weight of Chiller Panel 8.2 kg (18 lbs) 8.2 kg (18 lbs)
Refrigerants 1st Stage: R404A
2nd Stage: as indicated*
R290 & R508B
OR
R290 & R170
Each in varying amounts and sub-
stantially less than 500 g each.
1st Stage: R404A
2nd Stage: as indicated*
R290 & R508B
OR
R290 & R170
3rd Stage: R290 & R14
Each in varying amounts and substan-
tially less than 500 g each.
