Discovery TGA™ Getting Started Guide Page 21
Primary Function Buttons
Use the following buttons for the main functions of the instrument.
Table 1: Primary Function Buttons on the User Interface
Key Name Description
Start Begins the currently-programmed experiment. This is the same function
as Start on the instrument control software. Start automatically loads
the selected sample pan and closes the furnace, if necessary, before
beginning the experiment.
Stop If an experiment is running, this button ends the method normally, as
though it had run to completion; i.e., the method-end conditions go into
effect and the data that has been generated is saved. This is the same
function as Stop on the instrument control software. If an experiment is
not running (the instrument is in a standby or method-end state), the
Stop button will halt any activity (air cool, all mechanical motion, etc.).
If an Autosampler sequence is in progress, Stop will halt the sequence.
Furnace Open/Close Toggles between opening and closing the TGA furnace.
Tare Autoloader: Zeros the weight of an empty sample pan.
Autosampler: Displays a screen that allows you to choose the sample
pan to tare.
Pan Load/Unload Autoloader: Loads and unloads a sample pan.
Autosampler: Displays a screen that allows you to choose the pan posi-
tion to load/unload.
Back Returns you to the previous page used
Home Returns you to the Main screen.
