-14-
11.2 Electrical Ratings:
Model VR15L VR15M VR15H VR20L VR20M VR20H VR25L VR25M VR25H VR30L VR30M VR30H
Input Voltage
All single phase, 47 To 63 Hz)
110/240 110/240 200/240 110/240 110/240 200/240 200/240 200/240 200/240 200/240 200/240 200/240
Max Power (HP) 0.37 0.65 0.91 0.5 0.75 1.1 0.75 1.1 2.1 1.1 1.9 2.1
Max Power (W) 270 480 680 370 560 820 560 810 1550 800 1380 1550
Rated Current (A) 1.2 2.1 2.9 1.7 2.4 3.6 2.5 3.5 6.6 3.5 6 6.6
Current Limit (Max) (A) 6 6 6 6 6 6 6 6 8 6 8 8
24V Supply Output Max current up to 100 mA, Output voltage of 24V +/_ 20%, Output ripple under 1V
Relay Output 8A, Maximum Voltage 250 VAC, 48 VDC, Load up to 500 VA
Digital Inputs
Maximum Input Voltage: 32 VDC
2 Inputs, 1 output
Logical»1«Voltage> 8V,Logical»0«Voltage< 2V
Ethernet
RJ-45 Connector
Services: http server and client, FTP server
