SPECIFICATIONS
Model Name
TAD Compact Evolution One
Model No.
TAD-CE1
Design
Bass reflex, bookshelf-type speaker
Drive units
Bass driver ....................................................18 cm (7 1/16 in.) cone
Midrange/Tweeter
.... concentric 14 cm (5 1/2 in.) cone/ 3.5 cm (1 3/8 in.) semi-dome
Performance Data
Frequency Range .....................................................34 Hz to 100 kHz
Crossover Frequencies ......................................... 250 Hz, and 2 kHz
Maximum input power ............................................................. 200 W
Sensitivity ..............85 dB @ 2.83 V and 1 m (anechoic conditions)
Impedance .............................................................................. 4 ohms
Physical Data
Weight ........................................................................... 30 kg (66 lbs)
Dimensions
Width ............................................................ 290 mm (11 7/16 in.)
Height ............................................................. 524 mm (20 5/8 in.)
Depth ............................................................ 446 mm (17 9/16 in.)
Supplied accessories
Accessory folder
This Owner’s Manual x 1
Cleaning cloth x 1
Warranty card (This warranty is valid only in Japan.)
Accessory parts
Shorting links x 2
Note
Included parts may vary slightly by region.
The specifications and construction details in this and related
TAD publications are subject to change without notice. The TAD
logo is a registered trademark of Technical Audio Devices, Inc.
290mm
524mm
520mm
446mm
412mm
206
mm
155mm
Figure 6. Overall dimensions of the TAD Compact Evolution
One speaker system
The cabinet of this speaker system utilizes genuine wood materials.
While each unit displays beautiful depth of color and sheen, the use of woods makes absolute uniformity impossible, so no two units
will appear exactly the same.
Please keep this fact in mind when using the speakers.
Screw hole (M5) for
linking stand to speaker
