tae TA-U65 HT User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 2
01: EEPROM, SMC and EZU
ID
Name
Value-Range
Default-Value
Unit
Access
7
RTC Day
1 ... 31
---
d
R
8
RTC Month
1 ... 12
---
mon
R
9
RTC Year
2007 ... 2099
---
y
R
11
N Read Errors
0 ... 65535
---
NONE
12
N Write Errors
0 ... 65535
---
NONE
14
main_state_dsp_check
0 ... 65535
---
NONE
15
init_counter_dsp_check
0 ... 1
---
NONE
16
test1_counter_dsp_check
0 ... 65535
---
NONE
17
test2_counter_dsp_check
0 ... 65535
---
NONE
01: EEPROM, SMC and EZU
ID
Name
Value-Range
Default-Value
Unit
Access
19
Peripherals
0000h ... 00FEh
---
[bits]
R
Display of existing circuit board options
Bit
Name
Notes
0
1
CanOpenPCBoard
2
ProfibusPCBoard
3
EthernetPCBoard
4
ADIOPCBoard
5
TaeEncoderPCBoard
6
422EncoderPCBoard
7
ResolverPCBoard
02: Motor Data
ID
Name
Value-Range
Default-Value
Unit
Access
20
Motor Type
[00] ASM_UF ... [04] SM_SL
---
RW
Selecting the motor type:
No.
Name
Notes
0
ASM U/F
Asynchronous motor operated with voltage/frequency characteristics
1
ASM Sensor
Vector controlled asynchronous motor with rotation speed sensor
2
ASM Sensorless
Vector controlled asynchronous motor without rotation speed sensor
3
Syn Sensor
Synchronous motor with rotor position and rotation speed sensor
4
Syn Sensorless
Synchronous motor without “sensorless”rotation speed sensor
02: Motor Data
ID
Name
Value-Range
Default-Value
Unit
Access
21
Article Number (TAE)
0 ... 65535
---
RW
22
Motor Size
0 ... 65535
---
RW
02: Motor Data
ID
Name
Value-Range
Default-Value
Unit
Access
23
Kind of Winding
[00] Star ... [01] Delta
[00] Stern
RW
Choosing the method of connection:
Not in use, always choose the star connection
Nr.
Name
0
Star
1
Delta
