Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 11
09: Analog I/O
ID
Name
Value-Range
Default-Value
Unit
Access
270
A-OUT 76 Mode
[00] 0~10V ... [05] 0~-10V
[00] 0~10V
RW
271
A-OUT 76 Offset
-32767 ... 32767
---
RW
272
A-OUT 76 Gain
0,00 ... 105,00
100,00
RW
273
A-OUT 76 Src-Parameter
0 ... 1200
522
RW
274
A-OUT 76 Norm Value
0 ... 32767
---
RW
275
A-OUT 76 Act Value
-32767 ... 32767
---
R
09: Analog I/O
ID
Name
Value-Range
Default-Value
Unit
Access
280
Temp22 Motor Sensor Type
[00] Klixon ... [04] PTC-Thermistor
[00] Klixon
RW
281
Temp22 Motor Offset
-320,0 ... 320,0
0,0
1)
°Cel
RW
282
Temp22 Motor Gain
0,0 ... 200,0
100,0
1)
RW
283
Temp22 Motor Act Value
-320,0 ... 320,0
0,0
°Cel
R
285
Temp21 Motor pre warn Sensor Type
[00] Klixon ... [04] PTC-Thermistor
[01] PT100
RW
286
Temp21 Motor pre warn Offset
-320,0 ... 320,0
0,0
1)
°Cel
RW
287
Temp21 Motor pre warn Gain
0,0 ... 200,0
100,0
1)
RW
288
Temp21 Motor pre warn Act Value
-320,0 ... 320,0
---
°Cel
R
290
Temp Drive Sensor Type
[00] Klixon ... [04] PTC-Thermistor
[01] PT100
RW
291
Temp Drive Offset
-320,0 ... 320,0
0,0
1)
°Cel
RW
292
Temp Drive Gain
0,0 ... 200,0
100,0
1)
RW
293
Temp Drive Act Value
-320,0 ... 320,0
---
°Cel
R
Zero point or. offset setting when using a PT-100 or a KTY.
Because the measurement can be corrupted by the resistivity of the cable.
(at complete delivery, adjusted by TAE)
Select motor temperature sensor for terminal 21, 22
Select drive temperature sensor
Nr.
Name
Notes
0
Klixon
Thermal switch (break contact)
1
PT-100
Thermal resistance 100Ohm at 0°C
2
KTY-83
Note the input amplification. (jumper on the encoder board, see wiring diagram)
3
KTY-84
Note the input gain. (jumper on the encoder board, see wiring diagram)
4
PTC-Thermistor
In case the resistance is higher than 150Ohm at 25°C:
Take the input amplification into account. (jumper on the encoder board, see wiring
diagram)
10: PLC I/O
ID
Name
Value-Range
Default-Value
Unit
Access
300
PLC-IO CMD
0000h ... 00F3h
0000h
[bits]
RW
Bit
Name
Notes
0
Reload CFG
Re-load the parameters / configuration
1
Clear CFG
Reset the parameters / configuration
2
3
4
Susp: All
Stop all functions
5
Susp: GetIN
Stop reading the inputs
6
Susp: Calc
Stop calculating the outputs
7
Susp: SetOut
Stop setting the outputs
8…15
