tae TA-U65 HT User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 31
23: Trace
ID
Name
Value-Range
Default-Value
Unit
Access
1010
trigger type
[00] > v (immediate) ... [07] Bit=0 (on edge)
[04] Bit=1 (sofort)
[bits]
Bit
Name
Comments
0
> v (immediate)
Trigger remains active until the comparison value is exceeded
1
< v (immediate)
… remains active until the comparison value cannot be met
2
> v (on edge)
… is currently active, as soon as the comparison value is exceeded
3
< v (on edge)
… is currently active, as soon as the comparison value cannot be met
4
Bit=1 (immediate)
… active as long as all the Bits set in the reference value are present in the Trigger
parameters
5
Bit=0 (immediate)
… active as long as all the Bits set in the reference value are 0 within the Trigger parameters
6
Bit=1 (on edge)
… will become active once all the Bits set in the reference value are 1 in the Trigger
parameters
7
Bit=0 (on edge)
... will become active once all the Bits set in the reference value are 0 in the Trigger
parameters
● Reference value: (Par.1013)
● Comparison value: (Par.1014)
23: Trace
ID
Name
Value-Range
Default-Value
Unit
Access
1011
trigger parameter id
0 ... 4294967295
560
RW
1012
trigger parameter decimals
-1 ... 10
0
RW
1013
trigger compare value
-1000000 ... 1000000
0
RW
1014
trigger actual value
-1000000 ... 1000000
---
R
1015
trigger time-stamp
0 ... 4294967295
---
R
1020
sample dilation factor
1 ... 10000
1
RW
1021
sample time tick
0,000 ... 100000000,000
---
us
R
1022
sample time period
0,000 ... 100000000,000
---
us
R
1023
trace time total
0,000 ... 100000000,000
---
ms
R
1024
sample size
0 ... 16
---
B
R
1025
n sample buffer size
0 ... 65535
2048
W
R
1026
n samples available
0 ... 65535
---
R
1027
trace sample running
0 ... 65535
---
R
1030
param ch #1
0 ... 4294967295
0
RW
1031
param ch #2
0 ... 4294967295
0
RW
1032
param ch #3
0 ... 4294967295
0
RW
1033
param ch #4
0 ... 4294967295
0
RW
1034
param ch #5
0 ... 4294967295
0
RW
1035
param ch #6
0 ... 4294967295
0
RW
1036
param ch #7
0 ... 4294967295
0
RW
1037
param ch #8
0 ... 4294967295
0
RW
1040
sample bank select
-1 ... 65535
0
RW
1041
sample act time-stamp
0 ... 4294967295
---
us
R
1042
sample value #1
0 ... 4294967295
---
R
1043
sample value #2
0 ... 4294967295
---
R
1044
sample value #3
0 ... 4294967295
---
R
1045
sample value #4
0 ... 4294967295
---
R
1046
sample value #5
0 ... 4294967295
---
R
1047
sample value #6
0 ... 4294967295
---
R
1048
sample value #7
0 ... 4294967295
---
R
1049
sample value #8
0 ... 4294967295
---
R
