XT-3 Reader Installation Manual & Data Sheet Doc no. 11-267 02
© TagMaster NA 19 (28)
A cable for connecting the service interface to a 9-pin PC COM port should be created
as specified in Table 13.
Table 13 Cable specification: PC COM port
↔
Reader Service Interface
9-pin D-sub Connector
(female on cable)
Reader Connector
Pin Signal Pin Signal
2 RXD 1 TX
3 TXD 2 RX
5 GND 3 GND
5.2.9 Isolated Inputs, Group J51
The reader has three isolated optocoupler inputs which are protected from noisy
environments.
Table 14 Isolated Inputs, Group J51
Pin Signal Description
1 IN 1A Input signal 1
2 IN 1C Input reference 1
3 IN 2A Input signal 2
4 IN 2C Input reference 2
5 IN 3A Input signal 3
6 IN 3C Input reference 3
5.2.10 Isolated Outputs, Group J52
This group is in the XT-3 pre-configured with cables to power (J31) and an M12-4
connector in the chassis to support the LEDs of the external antenna. If required the
pre-configuration can be removed and the group used for other purposes.
The group consists of two open collector outputs.
Table 15 Isolated Outputs, Group J52
Pin Signal Description
1 OUT 1C Output 1 collector
2 OUT 1E Output 1 emitter
3 OUT SPL External supply voltage for the outputs
4 OUT 2C Output 2 collector
5 OUT 2E Output 2 emitter
5.2.11 Ethernet, Connector P1
An RJ45 connector labelled P1, with two internal indicators, is provided for Ethernet
connection. The clip for detaching the cable faces upwards from the controller board
surface to allow mid-board mounts. The Ethernet connector has eight pins and the wire
scheme is based on the T568A standard.
