XT-3 Reader Installation Manual & Data Sheet Doc no. 11-267 02
© TagMaster NA 20 (28)
Note: The RJ45 connector will not pass through the cable gland. Pass the Ethernet
cable through the cable gland, before crimping the connector on the cable.
5.2.12 USB Host, Connector P2
USB devices are connected using a standard USB type A connector.
5.2.13 Micro SD Memory Card Interface, Socket P3
A standard micro SD memory card socket is used. The card socket is placed on the
underside of the controller board.
