3-6
3.4.2 (For TPR-1600H)
Motor Part Name Rated Power Capacity Maximum Initiate Power
Main Motor
5.625kw 15.75kw
Elevating Motor
1.5kw 4.2kw
Hydraulic Motor
0.75kw 2.1kw
Coolant Pump Motor
0.1kw 0.28kw
Total Rated Power Capacity:
(5.625kw+1.5kw+0.75kw+0.1kw)=7.975kw…………….(1)
Maximum Total Initiate Power Capacity:
(15.75kw+4.2kw+2.1kw+0.28kw)=22.33kw…………….(2)
Transformer Rated Output Power Capacity for Control Circuits
Model
Item 100VA
Input
AC400V±10% 1∅
Power Supply
Output
AC240V±10% 1∅
Ambient Temperature 0°C To 55°C
S=KVA
P=KW
Pf ×n = 0.75 (Correction Factors)
S=
KW
Pf×n(0.75)
P=
7.975Kw
0.75
=10.633KVA………………….. (1)
P=
22.33Kw
0.75
=29.773KVA………………….. (2)
Power Equipment Capacity=
10.633KVA+29.773KVA
2
=20.203KVA
To Next Page
