9.7 Electrical main parts List (for TPR-1600H CE Standard)
Part No. Symbol Name Specification Q’ty Remark
E1602002 Key Switch XF323B 1
E3101023 FU4 Fuse 10*38*6A 1
E0703006 MS1 Magnetic Contact CU27 24V 1
E0703006 MS2 Magnetic Contact CU27 24V 1
E0703004 MS3 Magnetic Contact CU11 3a1b 24V 1
E0703004 MS4 Magnetic Contact CU11 3a1b 24V 1
E0703004 MS5 Magnetic Contact CU11 3a1b 24V 1
E0703004 MS6 Magnetic Contact CU11 3a1b 24V 1
E3101027 FU1 Fuse 10*38*20A 1
E3101027 FU2 Fuse 10*38*20A 1
E3101027 FU3 Fuse 10*38*20A 1
E1801030 TR Transformer 500VA
1:0,220,380,415,440v
2:0,24,110V
1
E1202013 Pilot
YK∅30 24V(G)
1
E1202013 Power (Alarm
Lamp)
YK∅30 24V(G)
1
E1701002 Work Lamp FS 51441 110V 1
E0207022 OL1 Overload relay RHN 18/12.5 1
E0207016 OL2 Overload relay RHN 10/3.5~5 1
E0207014 OL3 Overload relay RHN 10/1.4~2.1 1
E0703004 CR1 Magnetic Contact CU11 3a1b 24V 1
E0703004 CR2 Magnetic Contact CU11 3a1b 24V 1
E1604001 SS1 Selector Switch SN1021 1
E1303002 SS2 Selector Switch
YK∅30 1A1B
1
E1605008 SS3 Cross Switch TMR-305 1
E1203001 PB1 Emg. Push Button
YK∅30 1A1B (R)
1
E1202013 PB2 Push Button
YK∅30 1A1B 24V(G)
1
E1202012 PB3 Push Button
YK∅22 2A (B)
1
E1202012 PB4 Push Button
YK∅22 2A (B)
1
E0901013 LS1 Limit Switch WLD 1
E0901010 LS2 Limit Switch WLD2 1
E0901010 LS3 Limit Switch WLD2 1
E0901008 LS4 Limit Switch TZ8104 1
E0901008 LS5 Limit Switch TZ8104 1
E0208001 T1 Timer Relay ASTP-N 24V 6S 1
