9.6 Electrical main parts list (for TPR-1230 CE Standard)
Part No. Symbol Name Specification Q’ty Remark
E1602001
Key Switch XF163B 1
E0703004 M0 Magnetic Contact CU11 3a1b 24V 1
E0703004 MS1 Magnetic Contact CU11 24V 1
E0703004 MS2 Magnetic Contact CU11 3a1b 24V 1
E0703004 MS3 Magnetic Contact CU11 3a1b 24V 1
E0703004 MS4 Magnetic Contact CU11 3a1b 24V 1
E0703004 MS5 Magnetic Contact CU11 3a1b 24V 1
E0703005 MS6 Magnetic Contact CU18 24V 1
E0703005 MS7 Magnetic Contact CU18 24V 1
E3101027 FU1 Fuse 10*38*20A 1
E3101027 FU2 Fuse 10*38*20A 1
E3101027 FU3 Fuse 10*38*20A 1
E3101025 FU4 Fuse 10*38*6A 1
E1801020 TR Transformer 150VA
1:0,220,380 2:0,24,110
1
E0207018 OL1 Overload relay RHN 10/1.8~2.7 1
E0207018 OL2 Overload relay RHN 10/1.8~2.7 1
E0207017 OL3 Overload relay RHN 10/5.5~8.5 1
E1303002 SS1 Selector Switch
YK∅30 1A1B(B)
1
E0901021 SS2 Limit Switch V-15-1E5 4
E1604001 SS3 Selector Switch SN1021 1
E1603001 SS4 Pole change Switch A441 CA10 1
B100012 SS5 Push Button ZB4-BA2
ZB4-BZ101
ZBE-102
1
B100012 SS6 Push Button ZB4-BA2
ZB4-BZ101
ZBE-102
1
E2305001
Pilot
YK∅30 24V(W)
1
E2305001
Power (Alarm
Lamp)
YK∅30 24V(W)
1
E1701002
Work Lamp FS 51441 110V 1
E0901006 LS1 Limit Switch MJ2-1308R 1
E0901008 LS2 Limit Switch TZ 8104 1
E0901007 LS3 Limit Switch MJ2-1704 1
E0901007 LS4 Limit Switch MJ2-1704 1
