9-21
Part No. Symbol Description Specification Q’Ty Remarks
E0207016
OL3 Overload Relay RHN 10/3.5~5 1
For 200~230V
E0207017
OL1 Overload Relay RHN 10/5.5~8.5 1
For 380~460V
E0207018
OL2 Overload Relay RHN 10/1.8~2.7 1
For 380~460V
E0207014
E0207008
OL3 Overload Relay RHN 10/1.4~2.1 or RH18/1.7 1
For 380~460V
E0208004
T1 Timer Relay ASTP-N6S 110V 1
Standard
E0208004
T2 Timer Relay ASTP-N6S 110V 1
Standard
E0208001
T1 Timer Relay ASTP-N6S 24V 1
Optional
E0208001
T2 Timer Relay ASTP-N6S 24V 1
Optional
E3602001
Amp Meter S065 30A 1
Standard
M0302018
SOL1¸SOL2
Solenoid Valve DSG-3 C2-02 110V 1
Standard
M0302018
SOL3¸SOL4
Solenoid Valve DSG-3 C2-02 110V 1
Standard
M0302019
SOL1¸SOL2
Solenoid Valve DSG-3 C2-02 24V 1
Optional
M0302019
SOL3¸SOL4
Solenoid Valve DSG-3 C2-02 24V 1
Optional
Coolant Pump Motor
1/8HP 2P 3PH L:130mm 1
Elevating Motor Horizontal 1HP 4P 3PH 1
Main Motor 3HP/1.5HP 4P/8P 3PH 1
Hydraulic Motor Horizontal 1HP 4P 3PH 1
A
