TM8100 Mobile Radio Service Manual Disassembly and Re-assembly of Radio 143
May 2004 © Tait Electronics Limited
5. Separate the main board from the heat-transfer block. Avoid
touching or fouling the thermal paste on the copper plate and
heat-transfer block.
6. Replace any faulty connector. In the case of the power connector
note that, as well as the pins being soldered to the PCB, there are
two screws securing the connector. Use a Torx T10 screwdriver
to remove the screws. After replacing the connector, use a torque-
driver to tighten the screws to 0.34 N
·m (3 lbf·in).
Table 6.2 Contents of TMAA22-02 Spares kit 2 — mechanical parts of radio body
IPN Description Quantity Reference
— Cover assembly (see below for constituent parts) 1 Figure 2.8
349-02067-xx M4 x 16 screw for lid of radio body 4 Figure 2.8
362-01115-xx Control-head seal 1 Figure 2.8
362-01109-xx Main seal in lid 1 Figure 2.9
302-50000-xx Bung for external options connector 1 Figure 2.9
302-50001-xx Bung for auxiliary connector 1 Figure 2.11
362-01113-xx Seal for RF connector 1 Figure 2.11
349-02067-xx External M4 x 16 screw for main-board assembly 2 Figure 2.11
349-02066-xx Internal M3 x 10 screw for main-board assembly 5 Figure 2.11
362-01114-xx Rubber seal for power connector 1 Figure 2.12
354-01043-xx Lock-nut for auxiliary connector 1 pair Figure 2.12
362-01112-xx Outer foam seal for auxiliary connector 1 Figure 2.12
362-01110-xx Inner foam seal for auxiliary connector 1 Figure 2.12
Parts of cover assembly
303-23166-xx Cover 1 Figure 2.8
365-01712-xx Label for cover 1 Figure 2.8
Note
The characters xx in an IPN stand for the issue number. Items in the spares kit will always be the latest issue at
the time the spares kit is produced.
