TM8100 Mobile Radio Service Manual Diagnosis of Faults on Main Board 231
May 2004 © Tait Electronics Limited
Figure 9.28 Circuitry under the DIRC TOP can, the measurement point on L315, and the points for
attaching the test lead and test capacitor (D1 band)
DIRC
TOP
C350
C349
C348
L315
D1 BAND
MEASUREMENT POINT ON L315
MOUNTING POINT FOR TEST CAPACITOR
TEST PAD
