40 General Description TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 2.5 Interior of a control head with UI showing the parts remaining after the removal of the
space-frame
1
16
13
11
12
14
15
CAPSULE OF CONCEALED
MICROPHONE (OPTIONAL)
RUBBER SEAL FOR CONCEALED
MICROPHONE (OPTIONAL)
LIGHT PIPES
FOR STATUS LEDs
