TM8100 Mobile Radio Service Manual General Description 49
May 2004 © Tait Electronics Limited
Figure 2.12 Parts of the main-board assembly
13
17
14
18
16
15
THERMAL PASTE
THERMAL PASTE
DIGITAL BOARD
LOCK WASHER OF
RF CONNECTOR
HEXAGONAL NUT OF
RF CONNECTOR
RF CONNECTOR
POWER
CONNECTOR
MAIN BOARD
INTERNAL OPTIONS CONNECTOR
AUXILIARY CONNECTOR
