4.5 TOP Encryption Upgrade Flex PCB Information
At the time of printing, there are two current versions of the Flex PCB.The numbers appear on
the PCB top side. Be careful to ensure you are referring to the correct version information.
4.5.1 IPN 228-22592-06A
SMD Parts List IPN 228-22592-06A Non-SMD Parts List IPN 228-22592-06A
Part IPN Description
TS1 SMD PADS FOR 20W .3MM FLEX BD
0.5MM PITCH
PL1 COPPER-PAD SMD PADS FOR 22W .3MM FLEX BD 1MM
SPAN
PL2 COPPER-PAD SMD PADS FOR 22W .3MM FLEX BD 1MM
SPAN
P5 I/O-PAD SMD PADOFF BD WIRE CONN
P6 I/O-PAD SMD PADOFF BD WIRE CONN
P1 I/O-PAD PAD HOLE OFF BD WIRE CONN
P2 I/O-PAD HOLE OFF BD WIRE CONN
P4 I/O-PAD HOLE OFF BD WIRE CONN
P7 I/O-PAD HOLE OFF BD WIRE CONN
P8 I/O-PAD HOLE OFF BD WIRE CONN
P10 I/O-PAD HOLE OFF BD WIRE CONN
P11 I/O-PAD HOLE OFF BD WIRE CONN
P12 I/O-PAD HOLE OFF BD WIRE CONN
P13 I/O-PAD HOLE OFF BD WIRE CONN
P18 I/O-PAD HOLE OFF BD WIRE CONN
P19 I/O-PAD HOLE OFF BD WIRE CONN
P20 I/O-PAD HOLE OFF BD WIRE CONN
P21 I/O-PAD HOLE OFF BD WIRE CONN
P22 I/O-PAD HOLE OFF BD WIRE CONN
P24 I/O-PAD HOLE OFF BD WIRE CONN
P25 I/O-PAD HOLE OFF BD WIRE CONN
Part IPN Description
D1 001-10000-99 DIODE BAV99 DUAL SW (PIN 3 IS
ANODE/CATH)
IC1 002-15595-00 IC 74AHC595PW 8-BIT SHIFT REGISTER
C1 015-26100-08 CAP 100N 10% 50V X7R
C2 015-26100-08 CAP 100N 10% 50V X7R
C3 015-26220-08 CAP 220N 10% 16V X7R
R2 036-14470-10 RES 4K7 1%
R3 036-15470-10 RES 47K 1%
R4 036-15470-10 RES 47K 1%
P26 I/O-PAD HOLE OFF BD WIRE CONN
P27 I/O-PAD HOLE OFF BD WIRE CONN
P28 I/O-PAD HOLE OFF BD WIRE CONN
TP13 I/O-PAD HOLE OFF BD WIRE CONN
LINK1 LINK-0805-SP 0805 CHIP SPACING USED AS 3-WAY
LINK
LINK2 LINK-0805-SP 0805 CHIP SPACING USED AS 3-WAY
LINK
LINK3 LINK-0805-SP 0805 CHIP SPACING USED AS 3-WAY
LINK
LINK4 LINK-0805-SP 0805 CHIP SPACING USED AS 3-WAY
LINK
LINK8 LINK-0805-SP 0805 CHIP SPACING USED AS 3-WAY
LINK
LINK5 SOLDER-LINK SOLDER LINK WITH TWO SMD PADS
0.05 SPAC
LINK6 SOLDER-LINK SOLDER LINK WITH TWO SMD PADS
0.05 SPAC
LINK7 SOLDER-LINK SOLDER LINK WITH TWO SMD PADS
0.05 SPAC
