Tait TOP Programming And Service Manual

M2259-00-200-812 T2000 Radio Encryption 51
Copyright TEL Encrypted Radio Programming and Service Manual
5.5 T2000 Encryption Flex PCB Information
At the time of printing, there are two current versions of the Flex PCB. The numbers appear on
the PCB top side. Take care to ensure you are referring to the correct version information.
5.5.1 IPN 228-22593-01A
SMD Parts List IPN 228-22593-01A
Non-SMD Parts List IPN 228-22593-01A
Part IPN Description
C1 015-23150-01 CAP 150P 5% NPO 50V
C2 015-23150-01 CAP 150P 5% NPO 50V
C3 015-23150-01 CAP 150P 5% NPO 50V
C4 015-23150-01 CAP 150P 5% NPO 50V
C5 015-23150-01 CAP 150P 5% NPO 50V
C6 015-23150-01 CAP 150P 5% NPO 50V
C7 015-23150-01 CAP 150P 5% NPO 50V
C8 015-23150-01 CAP 150P 5% NPO 50V
SK1 240-10000-09 SKT 2-179397-4 24WAY 2ROW TOP
ENTRY SMD
Part IPN Description
C1 015-23150-01 CAP 150P 5% NPO 50V
C2 015-23150-01 CAP 150P 5% NPO 50V
C3 015-23150-01 CAP 150P 5% NPO 50V
C4 015-23150-01 CAP 150P 5% NPO 50V
C5 015-23150-01 CAP 150P 5% NPO 50V
C6 015-23150-01 CAP 150P 5% NPO 50V
C7 015-23150-01 CAP 150P 5% NPO 50V
C8 015-23150-01 CAP 150P 5% NPO 50V
SK1 240-10000-09 SKT 2-179397-4 24WAY 2ROW TOP
ENTRY SMD
