Parts List
Part No. Description Part No. Description
1 Case Assembly 65 O-ring P25
2 Brackets 66 Filter
3 Screw (W) M4 x 10 67 Packing
4 Back Guard Panel 68 Combustion Chamber
5 Transformer 69 Burner Assembly
6 Transformer 70 Screw M4 x 12
7 Junction Box 71 Wire Holder
8 Junction Box Cover 72 Spark Electrode Holder Packing
9 Screw M4 x 8 73 Spark Electrode Holder
10 Sound Insulation 74 Screw M4 x 10
11 Screw M4 x 8 (Coated) 75 Silicon Cap
12 Weather Protection Panel 76 Spark Electrode Fixing Plate
13 Front Cover 77 High Voltage Igniter Cable
14 Exhaust Pipe 78 O-ring (seal)
15 Heat Exchanger Assembly 79 Thermocouple
16 Hi-Limit Switch 80 Thermocouple Fixing Plate
17 Screw M3 x 6 81 Overheat Cut Off Fuse
18 Screw M4 x 10 (coated) 82 Damper
19 Outlet-Thermistor 83 Washer
20 O-ring P4 84 Pressure Switch Port
21 Heater Block 604 85 Silicon Tube
22 Heat Exchanger Fixing Plate (Back) 86 Pressure Switch
23 Heat Exchanger Fixing Plate (Front) 87 Fan Motor
24 Over Heat Cut Off Fuse Fixing Plate 88 Screw M4 x 12 Hex
25 Over Heat Cut Off Fuse 89 Thermostat
26 Heater Block Fixing Plate 90 Screw (W) M3 x 10
27 Inlet-Thermistor 91 Manifold
28 Two Way Valve Cover 92 Manifold Gas Pressure Port
29 Silicon O-ring M26 93 Gasket
30 Two Way Valve Assembly 94 Screw M4 x 12
31 O-ring P20 95 Manifold Gas Pressure Tap
32 Screw M4 x 8 96 Gas Coupling
33 Quick Release Plate 97 Screw M4 x 8 (Washer & Hex head)
34 O-ring JASO#1017 98 Igniter Fixing Plate
35 Screw M4 x 12 99 Igniter
To Next Page
