CASE 3: Wrong connections between the "CHILD-1" unit and the "CHILD-2" unit
• If you connect the “PARENT” connector of the “CHILD-1” unit to the “1” connector of the
“CHILD-2” unit, the “CHILD-2” unit will operate as an individual unit, and will not be part of the
Easy-Link System.
CASE 4: Remote controller connected to incorrect unit
• Either a temperature controller or a remote controller has to be connected to the “PARENT”
unit. If the remote controller is connected to a “CHILD” unit, it will only control that particular
individual “CHILD” unit and will not control the Easy-Link System as a whole.
• The temperature controller of the “CHILD” unit will not control the unit on the system.
Connecting two “PARENT” connectors together from two separate units may
damage the computer board. The communication cable has a female end and
amaleendsoit’simpossibletohaveaPARENT-to-PARENTconnectionwiththe
communication cable. Do not splice or modify connectors.
WARNING
Installa on
Installa on Manual
PARENTunit
CHILD-1 unit
CHILD-2 unit
Wrong
Connecons
Communicaon cable
Connectors Connectors Connectors
Lower bank of
DIPswitches
12
345
6
OFF
ON
OFF
ON
12
3
4
56
Lower bank of
DIPswitches
OFF
ON
1
2
3
456
Lower bank of
DIPswitches
PARENT
12
PARENT
12
PARENT
12
PARENTunit
CHILD-1 unit
Remotecontroller
WrongConnecons
Communicaon cable
2 1 2 1
PARENT PARENT
ConnectorsConnectors
OFF
ON
1
2
3
4
5
6
Lower bank of
DIPswitches
OFF
ON
1
2
3
4
5
6
Lower bank of
DIPswitches
