Takagi T-H3S-DV User Manual

54 Page
Troubleshoong
Owner's Guide
Remote
Green
LED
Malfunction
description
Diagnosis
391
Two Times Air-fuel ratio rod
failure
• Checkforconnection/breakageofwires(Part#709)
and/orsootontheAFRrod(Part#108).
441
Two Times Flow sensor failure
(Easy-Link System only)
• Check for connection/breakage of wires and/or
debris on the flow sensor impeller (Part #402).
510
Six Times Abnormal main gas
solenoid valve
• Check for connection/breakage of wires (Part #708)
and/orburnmarksonthecomputerboard(Part#701).
551
Six Times Abnormal gas
solenoid valve
• Check for connection/breakage of wires (Part #708)
and/orburnmarksonthecomputerboard(Part#701).
611
Four Times Fan motor fault • Check for connection/breakage of wires, dust buildup
inthe fanmotor(Part#103)and/orburnmarkson
thecomputerboard(Part#701).
• Checkforfrozen/corrosionofconnectors(Part#103).
651
Four Times Flow adjustment
valve fault (Easy-
Link System only)
• Inspect the flow adjustment valve (Part #402), for
connection/breakage of wires, locked motor drive
due to scale buildup, and/or water leakage.
661
Four Times Bypass valve fault
(540(T-H3)
model only)
• Inspect the bypass valve (Part #403), for connection/
breakage of wires, locked motor drive due to scale
buildup, and/or water leakage.
701
One Time Computer board fault • Checkforconnection/breakageofwires(Part#714).
711
One Time Gas solenoid valve
drive circuit failure
• Refertothe111and121errorcodes.
721
Six Times False flame
detection
• For indoor models, check if condensate drain is
installed on the vent collar of the water heater.
• Checkifthereisleakingfromheatexchanger(Part#401).
741
N/A Miscommunication
between water
heater and remote
controller
• Check the model type of the remote controller.
• Inspect the connections between the water heater
and remote controller.
• Check the power supply of the water heater.
751
N/A Miscommunication
between water heater
and temperature
controller (Indoor
models only)
• Inspect the connections between the water heater
and temperature controller.
• Check the power supply of the water heater.
761
N/A Miscommunication
in Easy-Link System
• Check if the connections between the parent unit
andthechildunitsarecorrect.Refertop.33to36.
941
Five Times Abnormal exhaust
temperature
(Indoor models
only)
• Check if the set temperature is higher than 140°F
(60°C)andthesystemisRecirculation.
991
Five Times Imperfect
combustion
• Check the gas type of the water heater.
• Inspect the environment around the water heater.
Determine how long the unit has been installed.
• Check the altitude/elevation of the area of where
the water heater is installed.
• Check if there is any blockage in the intake air and/
or exhaust.
• If the water heater is installed as a direct-vent system,
check whether there is enough distance between the
intake air terminal and the exhaust terminal.
• Check if there is grease and/or dirt in the burner (Part
#101)and the fanmotor(Part#103), especiallyif the
water heater has been installed in a contaminated area.
