Parts List
Owner's Guide
Item # Description
Part #
240, 340 and
540 models
T-H3J, T-H3S and
T-H3 models
116
117
118
Pressure port
Combustion chamber tube
Gas inlet
319143-042
319143-344
319143-455
EKK2D
EX019
EK117
119
121
Gas inlet ring
Surge box plate
319143-342
319143-522
EX00D
EK163
150
151
152
153
O-ringP18NBR(Black)
O-ring P20 NBR (Black)
Silicon ring for Outdoor models
Exhaust port for Outdoor models
319143-350
319143-057
319143-523
319143-524
EZP18
EK042
EK157
EK177
401 Primary heat exchanger assembly for 240 (T-H3J) and 340 (T-H3S) models
Primary heat exchanger assembly for540(T-H3)model
319143-547
319143-548
EK252
EK250
402
403
404
405
406
Flow adjustment valve / Flow sensor
Bypassvalvefor540(T-H3)model
Water inlet
Inlet drain plug
Inlet water filter
319143-463
319143-464
319143-193
319143-197
319143-198
EK129
EKD58
EKK1U
EKK2B
EKK2C
407 Inlet thermistor for 240 (T-H3J) and 340 (T-H3S) models
Inletthermistorfor540(T-H3)model
319143-214
319143-465
EKK4J
EK137
408 Outlet thermistor for 240 (T-H3J) and 340 (T-H3S) models
Outletthermistorfor540(T-H3)model
319143-529
319143-190
EK207
EKK1A
409
410
411
Water outlet
Outlet drain plug
Heatexchangerthermistorfor540(T-H3)model
319143-530
319143-199
319143-096
EK208
EKK2E
EKK2T
412 Hi-Limit switch for 240 (T-H3J) and 340 (T-H3S) models
Hi-Limitswitchfor540(T-H3)model
319143-228
319143-095
EM212
EKN34
413
414
Overheat-cut-off fuse
Pipe heater
319143-149
319143-531
EK333
EK209
415 Inlet heater for Indoor models
Inlet heater for Outdoor models
319143-532
319143-533
EK210
EK211
416
417
Drain tube
Inlet heater
319143-534
319143-468
EK231
EK105
418 Secondary heat exchanger for Indoor models
Secondary heat exchanger for Outdoor models
319143-549
319143-550
EK251
EK256
450
451
452
453
Pipe heater fixing plate
Heaterfixingplate16
Fusefixingplate18
Fusefixingplate14
319143-088
319143-125
319143-066
319143-146
EKK27
EK031
EKK26
EK029
454
455
456
457
O-ring P4 FKM
O-ringP6FKM
O-ringP14FKM
O-ringP15FKM
319143-082
319143-080
319143-100
319143-091
EZM04
EZM06
EZM14
EZM15
458
459
460
461
O-ringP16FKM
Fastener“4-11”
Fastener“14-22”
Fastener“16A”
319143-083
319143-097
319143-105
319143-226
EZM16
EKH30
EKK24
EM192
