Parts List
Part No. Description Part No. Description
1 Case Assembly 35 Screw M4 x 12
2 Brackets 36 Flange
3 Screw (W) M4 x 10 37 Flow Adjustment Valve
4 Back Guard Panel 38 O-ring P16
5 Transformer 39 Bypass Junction
6 Transformer 40 Screw M4 x 6
7 Junction Box 41 O-ring P18
8 Junction Box Cover 42 Water Outlet Connection
9 Screw M4 x 8 43 Screw M4 x 14
10 Sound Insulation 44 Mixing Thermistor
11 Screw M4 x 8 (Coated) 45 O-ring P6
12 Weather Protection Panel 46 Drain Plug
13 Front Cover 47 Mixing Connection
14 Exhaust Pipe 48 Drain Plug Band
15 Heat Exchanger Assembly 49 Water Outlet
16 Hi-Limit Switch 50 Screw (W) M4 x 12
17 Screw M3 x 6 51 Bypass Flow Adjustment Valve
18 Screw M4 x 10 (coated) 52 Bypass Valve
19 Outlet-Thermistor 53 Silicon O-ring M22
20 O-ring P4 54 Bypass Connection
21 Heater Block 604 55 O-ring JASO3 #1017
22 Heat Exchanger Fixing Plate (Back) 56 Clamp
23 Heat Exchanger Fixing Plate (Front) 57 Heater Fixing Plate
24 Over Heat Cut Off Fuse Fixing Plate 58 Screw M4 x 6
25 Over Heat Cut Off Fuse 59 Flow Sensor
26 Heater Block Fixing Plate 60 Heater 102
27 Inlet-Thermistor 61 Magnetic Protection Plate
28 Two Way Valve Cover 62 O-ring JASO #1019
29 Silicon O-ring M26 63 Screw M4 x 14 (coated)
30 Two Way Valve Assembly 64 Water Inlet
31 O-ring P20 65 O-ring P25
32 Screw M4 x 8 66 Filter
33 Quick Release Plate 67 Packing
34 O-ring JASO#1017 68 Combustion Chamber
To Next Page
