2-41
CONTROLS
INSTRUMENT CLUSTER
• Auxiliary 2nd flow rate setting
(2nd AUX SET)
Set the flow rate ratio for the Auxiliary 2nd
circuit.
a. For the key operation, refer to the Auxiliary
1st flow rate setting section.
Initial
condition
Standard flow
Variable
range
Auxiliary 2nd
C/D
100%=44 L/min
(11.6 US gpm)
10 to 100%
•
Auxiliary 4th flow rate setting
(4th AUX SET)
Set the flow rate ratio for the Auxiliary 4th
circuit.
a. For the key operation, refer to the Auxiliary
1st flow rate setting section.
Initial
condition
Standard flow
Variable
range
Auxiliary 4th
G/H
100%=44 L/min
(11.6 US gpm)
10 to 100%
