16
You determine the times for cycle switching commands
Symbols:
= ON switching duration (1...99 sec. or 1...99 min.)
= cycle duration (1...99 sec. or 1...99 min.)
The preselection for seconds or minutes is explained at the given time.
A cycle switching command consists of:
• Start time
• ON switching duration
• Cycle duration (ON switching duration + pause)
• End time
An end time is only required if the cycle must be ended at a certain
time. If you do not set an end time, the cycle switching commands
operate endlessly.
1. Example:
Start time Monday 09:00
ON switching duration
10 minutes
Cycle duration 60 minutes
End time Friday 19:00
2. Example:
Start time Monday to Friday 09:00
ON switching duration
10 minutes
Cycle duration 60 minutes
End time Monday to Friday 19:00
10. Cycle switching commands
Start time End time
Pause Pause
Cycle duration
60 min.
Cycle duration
60 min.
ON switching duration
10 minutes
