TalkTalk Super Router User Manual

12
4 Fit
Your router
1 Fit the microfilter with the grey
broadband cable attached into
your master phone socket.
2 Fit the phone cable or splitter
that you previously removed into
the port marked phone on the
microfilter.
3 Connect the other end of the grey
broadband cable into the grey
port labelled ‘Broadband’ at the
back of your Super Router.
IMPORTANT:
 <\fT`\VebÀ_fXefbTabf[Xec[baXbV^Xf\agX\abge[b`X
to ensure a strong and stable connection.
 DXhXec_gZ`\VebÀ_fXe\afbbf[Xe`\VebÀ_fXe$I[\i\__TYYXVf
your TalkTalk broadband performance.
 AXXcbgegcXeHbgfXeTiTYeb`bf[XeX_XVfe\VT_WXh\VX
(like baby monitors, microwaves, cordless phones or wireless speakers).
If you have a standard master socket...
1
2
3

TalkTalk Super Router Specifications

General

Antenna Type	Internal
Firewall	Yes
Parental Controls	Yes
Guest Network	Yes
Type	Wireless Router
Ethernet Ports	4
WAN Port	1
USB Ports	1
Security	WPA/WPA2
Frequency Bands	2.4GHz
